Fiber Adhesive
Moderate viscosity, good fiber wetting
Working life > 48 hours
Secures fiber, prevents peeling and breakage
Temperature range: -55 to +85°C
Description
Key Features
UV500 Winding Adhesive
Key Features
• Moderate viscosity, good fiber wetting
• Working life > 48 hours
• Secures fiber, prevents peeling and breakage
• Temperature range: -55 to +85°C
UV100 Pigtail Adhesive
Key Features
• Fast UV curing
• Low modulus, low stress
• Low additional loss at low temperature
• Safe, non-toxic, low water absorption
H01 Coil Bonding Adhesive
Key Features
• Two-component epoxy, excellent wetting
• Fast curing at 80°C medium temperature
• High bond strength, good toughness
• Temperature range: -50 to +120°C
Product Introduction
UV500 Winding Adhesive
UV500 is a curing adhesive for fiber-coil winding. It evenly coats the coil body to secure the wound fiber in its set state and prevent stripping and breakage. With moderate viscosity and good fiber wettability, it dispenses and pots easily. After curing, its wide operating-temperature range suits long-cycle winding.
UV100 Pigtail Adhesive
UV100 is a UV-curable silicone-rubber adhesive curing via siloxane addition crosslinking under UV light. As a fiber buffer layer, it removes stress from mechanical and thermal sources, protecting the fiber. Highly photo-crosslinking-sensitive, the cured gel is uniform, soft, and low-stress, keeping low modulus over its operating range. With low water absorption and excellent low-temperature performance, it cuts temperature-induced fiber loss. Safe to store and use, its curing is adjustable.
H01 Fiber Coil to Substrate Bonding Adhesive
H01 is a two-component epoxy adhesive bonding fiber coils to metal substrates. At a fixed mass ratio it has low viscosity, good wettability to coils and devices, long pot life, fast mid-temperature cure. Cured, it gives high bond strength and toughness, resists thermal/humidity-heat shock, serves a wide range, and has long room-temperature sealed shelf life.
Unique Technology
Company is a high-tech enterprise with full closed-loop capabilities from fiber winding equipment and coils to FOGs, fiber/MEMS inertial products, IMU circuits, software, and test equipment. End-to-end process control improves quality and reduces costs. Operating under ISO9001 with strict processes, it ensures product reliability and consistency.
Parameters
UV100/UV500/H01 Fiber Adhesive Specifications
UV500 Winding Adhesive:
|
Typical Data at 25°C |
Viscosity (mPa·s) |
Working Time (h) |
||
|
Modulus (MPa) |
Strength (MPa) |
Elongation (%) |
||
|
387 |
17 |
19 |
6747 |
＞48 |
UV100 Pigtail Adhesive:
|
Parameter |
Condition |
Specification |
|
Appearance |
-- |
Translucent or transparent liquid |
|
Composition |
-- |
Polysiloxane |
|
Active Content |
-- |
100% |
|
Viscosity (mPa·s) |
25℃ |
2000~3000 |
|
Density (g/cm³) |
25℃ |
0.95~1.10 |
|
Refractive Index |
25℃ |
1.41~1.42 |
|
Elastic Modulus (MPa) |
25℃ |
≤1 |
|
UV Curing |
≤10s, @365nm,200mw/cm2 |
Surface cure (curing time and intensity adjustable per actual requirements) |
H01 Coil Bonding Adhesive:
|
Physical Properties (Test Conditions) |
Typical Data |
|
|
Appearance |
Component A |
Component B |
|
White transparent liquid |
Light brown transparent liquid |
|
|
Pot Life |
≤5h |
|
|
Mixing Ratio (by weight) |
A:B=10:1 |
|
|
Curing Process |
80℃>2h |
|
|
Viscosity (25℃) ,mPa.s |
3899 |
|
|
Tensile Strength (25℃) ,MPa |
53 |
|
|
Hardness (shore D) |
96.1 |
|
|
Storage Life |
12 months (25℃) |
|
